| # | код | цена | кол-во в узле |
|---|---|---|---|
| 1 | 7517277 Винт |
477.47р под заказ |
|
| 2 | 5432533 Крышка |
3'323.67р под заказ |
|
| 3 | 3021413 Breather-valve Cr |
-- под заказ |
|
| 4 | 7516822 Винт |
-- под заказ |
|
| 5 | 2203004 Kit-valve Cover |
8'643.67р под заказ |
|
| 6 | 5411862 Seal-o-ring, .125 Hollow |
4'919.67р под заказ |
|
| 7 | 7518240 Scr-m12x1.75x180 Hx/fl-cylhead ([if Built Before 10/02/03] ) |
1'993.67р под заказ |
|
| 7 | 7518274 Bolt-head, M11x1.25, Sems ([if Built After 10/02/03] ) |
-- под заказ |
|
| 8 | 5811511 Gasket, 26mm Id |
5'052.67р под заказ |
|
| 10 | 7516730 Asm., Screw And Washer ([if Built Before 10/02/03] ) |
1'062.67р под заказ |
|
| 10 | 7518234 Scr-m8x1.25x25 Hx/soc Sems ([if Built After 10/02/03] ) |
397.67р под заказ |
|
| 11 | 1202425 Asm-cylinder Head Leclaire ([if Built Before 10/02/03] ) |
101'291.31р под заказ |
|
| 11 | 3021483 Head-cylinder ([if Built After 10/02/03] ) |
-- под заказ |
|
| 11 | 5131429 Guide, Valve, 6mm |
1'993.67р под заказ |
|
| 12 | 5812193 Gasket-cylinder Head, Twin, 1lyr ([if Built Before 10/02/03] ) |
6'552.75р под заказ |
|
| 12 | 5247359 Gasket-head ([if Built After 10/02/03] ) |
6'552.75р под заказ |
|
| 13 | 2202158 Kit-cylinder 80mm Twin Atv ([incl. 15][if Built Before 10/02/03] ) |
65'168.67р под заказ |
|
| 13 | 2203911 Kit-cylinder, Atv, 5136469 ([incl. 15][if Built After 10/02/03] ) |
75'808.67р под заказ |
|
| 14 | 5811455 Gasket-cylinder Base ([if Built Before 10/02/03] ) |
3'589.67р под заказ |
|
| 14 | 5247360 Gasket-base ([if Built After 10/02/03] ) |
3'589.67р под заказ |
|
| 15 | 7051534 Plug-expansion 1 1/8" |
424.27р под заказ |
|
| 17 | 7080681 Хомут |
1'062.67р под заказ |
|
| 18 | 7516734 Винт |
530.67р под заказ |
|
| 19 | 1253415 Adapter-carburetor |
11'968.67р под заказ |
|
| 20 | 3021671 Sparkplug-champion Rc7yc3 (4) |
557.27р под заказ |
|
| 22 | 5631196 Cover-thermostat W/o Bypass ([if Built Before 10/02/03] ) |
-- под заказ |
|
| 22 | 5632174 Cover-thermostat W/o Bypass ([if Built After 10/02/03] ) |
-- под заказ |
|
| 23 | 7052308 Thermostat-82c W/o Bypass ([if Built Before 10/02/03] ) |
10'638.67р под заказ |
|
| 23 | 7052352 Thermostat-w/by Pass ([if Built After 10/02/03] ) |
7'978.67р под заказ |
|
| 24 | 5411521 Кольцо |
1'594.67р под заказ |
|
| 25 | 4010356 Switch-temperature, 110c |
6'648.67р под заказ |
|
| 26 | 7052135 Fitting ([if Built Before 10/02/03] ) |
1'594.67р под заказ |
|
| 26 | 7052145 Fitting ([if Built After 10/02/03] ) |
1'062.67р под заказ |
|
| 27 | 7661175 Dowel-hol, M16x12, 0600089 ([if Built After 10/02/03] ) |
397.67р под заказ |
Каталог несет в первую очередь справочную информацию, поэтому обращаем ваше внимание, что наличие деталей в каталоге не означает ее наличие на нашем складе.
