| # | код | цена | кол-во в узле |
|---|---|---|---|
| 1 | T2108413 Radiator Cover, Lh Serial Number 227063 And Higher |
11'842.32р под заказ |
|
| 1 | T2108513 Spares Kit, Rad Cover, Lh Serial Number 227062 And Below |
13'065.92р под заказ |
|
| 1 | T2100715 Термостат |
9'295.37р под заказ |
|
| 2 | T2100713 O-ring, 48.9 X 2.62 |
453.53р под заказ |
|
| 2 | T2108414 Radiator Cover, Rh Serial Number 226086 And Higher |
11'842.32р под заказ |
|
| 2 | T2108514 Spares Kit, Rad Cover, Rh Serial Number 226085 And Below |
13'065.92р под заказ |
|
| 3 | T2100147 Elbow, Water, Cyl Hd, Silver Serial Number 241569 And Below |
5'712.35р под заказ |
|
| 3 | T3331518 Screw, But/hd, M6x1.0x20, Slv ""serial Number 89737 And Higher - M6 X 20mm, S/s"" |
671.65р под заказ |
|
| 3 | T2100146 Elbow, Water, Cyl Head, Black Serial Number 241570 And Higher |
5'115.18р под заказ |
|
| 4 | T3205066 Bolt, Rhhf, M6x1x20, Slv |
571.90р под заказ |
|
| 4 | T2108518 Spares Kit, Rad Cover, Lwr Serial Number 225059 And Below |
12'572.49р под заказ |
|
| 4 | T2108418 Radiator Cover, Lower Serial Number 225060 And Higher |
11'485.88р под заказ |
|
| 5 | T3330999 Screw, But/hd, Skt, M6x1.0x12, S/s |
473.48р под заказ |
|
| 5 | T2108304 Hose, Coolant, Rad To Thermost |
3'025.75р под заказ |
|
| 6 | T2108326 Hose, Coolant, Bypass |
3'157.42р под заказ |
|
| 6 | T2100069 Cap, Radiator, Chrome |
4'440.87р под заказ |
|
| 7 | T2108306 Hose, Coolant, Rad To Pump |
2'972.55р под заказ |
|
| 7 | T3333333 Screw, Tritap.m3x0.5x3, Brt |
517.37р под заказ |
|
| 8 | T3332568 Screw, But/hd, Skt, M5x0.8x8, Slv Serial Number 45788 To 71698 M5 X 8mm |
493.43р под заказ |
|
| 8 | T2108303 Hose, Coolant, Pump Oulet |
3'209.29р под заказ |
|
| 9 | T2102242 Hose Clip Bright |
1'006.81р под заказ |
|
| 9 | T2108417 Radiator Cover, Upper |
11'485.88р под заказ |
|
| 10 | T2100297 Grille Assy, Radiator, Front |
12'786.62р под заказ |
|
| 10 | T2102282 Clip, Hose, 16-27, Bright Ss Bright |
1'078.63р под заказ |
|
| 11 | T3700171 Clip, Hose, 10-16, Bright |
888.44р под заказ |
|
| 11 | T2100295 Grille Assy, Radiator, Lh Rear |
20'080.34р под заказ |
|
| 12 | T2100296 Grille Assy, Radiator, Rh Rear |
20'080.34р под заказ |
|
| 12 | T2108301 Помпа водяная Serial Number 241570 And Higher |
25'000.01р под заказ |
|
| 13 | 3600160T0301 o Ring Water Pump |
1'145.13р под заказ |
|
| 13 | T2108350 Pad, Foam, Radiator |
196.84р под заказ |
|
| 14 | T2108308 Вентилятор |
51'985.71р под заказ |
|
| 14 | T3600161 Seal, Water Pump Cover |
750.12р под заказ |
|
| 15 | T3550542 Washer, Cu, Od12.5, Id6.4, 0.8 M6 |
196.84р под заказ |
|
| 15 | T3331517 Screw, Torx P.h., Shld, M6*16, Blk M6 X 16mm |
196.84р под заказ |
|
| 16 | T2108307 Радиатор в сборе |
125'719.58р под заказ |
|
| 16 | T3330804 Bolt, Flange M6x25 M6 X 25mm |
196.84р под заказ |
|
| 17 | T3203050 Bolt, Rhhf, Domed S/less M6x50 ""rhhf, M6 X 50, S/less"" |
848.54р под заказ |
|
| 17 | T3021200 Grommet, Dia 14.0 X 4.0 Panel Serial Number 55899 And Higher |
395.01р под заказ |
|
| 18 | T3010100 Flanged Sleeve, Plated |
284.62р под заказ |
|
| 18 | T2108302 Water Pipe, Pump To Crankcase |
4'717.51р под заказ |
|
| 19 | T3600910 O-ring, Id17.86, 2.62t |
236.74р под заказ |
|
| 19 | T3350091 Nut, Captive, M6, Black |
296.59р под заказ |
|
| 20 | T2108300 Tank, Coolant Expansion |
12'335.75р под заказ |
|
| 21 | T3622511 Pipe, Coolant, Overflow |
1'341.97р под заказ |
|
| 21 | T3205083 Bolt, Hhf, Lghtd, M6x1.0x28, Slv M6 X 28mm |
315.21р под заказ |
|
| 22 | T3622512 Pipe, Coolant, Exp Tank To Rad |
1'460.34р под заказ |
|
| 22 | T2108309 Bracket, Radiator, Lower |
790.02р под заказ |
|
| 23 | T3331189 Screw, Pan/hd, Tx, M6x1.0x12, Enc M6 X 12mm Silver |
262.01р под заказ |
|
| 23 | T3700440 Clip, Hose, 11.0-12.5mm Pipe |
690.27р под заказ |
|
| 24 | T3330334 Screw, Tx, Pan/hd, M6x1.0x16, Slv ""rhhf, Domed, M6 X 16, S/less"" |
335.16р под заказ |
|
| 24 | T3551290 Washer, Nylon, 14.0x6.4x1.2 Serial Number 227709 And Higher |
553.28р под заказ |
|
| 24 | T3010400 Compression Limiter, M6 Serial Number 214510 And Higher (11 Required Ser No 214509 And Below; 9 Required Ser No 214510 To 225059; 4 Required Ser No 225060 To 226086; 2 Required Ser No 226086 To 227062; 0 Required Ser No 2270 |
553.28р под заказ |
|
| 25 | T2108310 Bracket, Expansion Tank |
591.85р под заказ |
|
| 25 | T3331518 Screw, But/hd, M6x1.0x20, Slv M6 X 20mm |
671.65р под заказ |
|
| 26 | T2101800 Cover, Linkage, T-body |
1'577.38р под заказ |
|
| 26 | T2108319 Bracket, Radiator, Lower, Rh |
790.02р под заказ |
|
| 27 | T2100405 Elbow, I.d. 8.0, Tube Eng No 89737 And Higher |
196.84р под заказ |
|
| 27 | 3350021T0301 Nut, Captive, M6 M6 |
212.80р под заказ |
|
| 28 | T3010500 Flanged Sleeve, M6x3.65 Serial Number 214510 And Higher |
553.28р под заказ |
|
| 28 | T2101002 Cap, Expansion Tank Expansion Tank |
215.46р под заказ |
|
| 29 | T3550188 Washer, Foam, Od15, Id9.4, 1.5 Serial Number 214510 And Higher |
553.28р под заказ |
|
| 29 | T3550603 Washer, 6.5x20x2 M6 Hardened |
196.84р под заказ |
|
| 30 | T2108330 Protector, Hose, Id 27.5 |
-- под заказ |
|
| 31 | T3700840 Clip, Water Hose |
196.84р под заказ |
|
| 32 | T2102113 Clip, Hose, 20-32,bright Ss Bright |
986.86р под заказ |
