| # | код | цена | кол-во в узле |
|---|---|---|---|
| 1 | 404103700 Couvercle Carb.*top-mix.chamb. Skandic Wide Track Lc. |
3'522.70р под заказ |
|
| 2 | 404104100 Ressort *spring Skandic Wide Track Lc. |
1'071.13р под заказ |
|
| 3 | 404103000 Plaque *plate Skandic Wide Track Lc. |
1'181.90р под заказ |
|
| 4 | 404160100 Tuyau Aeration *tube-air Vent Skandic Wide Track Lc. |
1'031.42р под заказ |
|
| 5 | 404121300 Vis W.rondelle*screw-with Washer Skandic Wide Track Lc. |
638.50р под заказ |
|
| 6 | 404101900 Aiguille 6dh04 *needle Jet Skandic Wide Track Lc. |
2'090.00р под заказ |
|
| 7 | 404102400 Bride A Ressort*clamp-spring Skandic Wide Track Lc. |
-- под заказ |
|
| 8 | 404160500 Guide *guide Holder Skandic Wide Track Lc. |
925.87р под заказ |
|
| 9 | 404128400 Tiroir Acc.2.5 *piston-val.2.5 Skandic Wide Track Lc. |
13'883.87р под заказ |
|
| 10 | 404100700 Gicleur Aiguil.*jet Needle Skandic Wide Track Lc. |
2'049.25р под заказ |
|
| 11 | 404104200 Joint *gasket Skandic Wide Track Lc. |
544.45р под заказ |
|
| 12 | 404107700 Gicleur Ralenti*jet-pilot 30 Skandic Wide Track Lc. |
378.29р под заказ |
|
| 13 | 404103300 Goupille Levier*pin-lever Skandic Wide Track Lc. |
638.50р под заказ |
|
| 14 | 404160700 Bras Flotte *arm-float Skandic Wide Track Lc. |
-- под заказ |
|
| 16 | 404101500 Rondelle *washer Skandic Wide Track Lc. |
483.84р под заказ |
|
| 17 | 404160600 Vis *screw Skandic Wide Track Lc. |
-- под заказ |
|
| 18 | 404102300 Screw-air Skandic Wide Track Lc. |
1'597.81р под заказ |
|
| 19 | 404101800 Ressort *spring Skandic Wide Track Lc. |
483.84р под заказ |
|
| 20 | 404101700 Ressort *spring Skandic Wide Track Lc. |
439.95р под заказ |
|
| 21 | 404102800 Vis Ajustement*screw-idle Speed Skandic Wide Track Lc. |
1'806.81р под заказ |
|
| 23 | 404101600 Rondelle Siege *washer-seat Skandic Wide Track Lc. |
354.26р под заказ |
|
| 24 | 404147400 Pointeau Vs 1.5*valve Needle Skandic Wide Track Lc. |
6'927.31р под заказ |
|
| 25 | 404102200 Rondelle *washer Skandic Wide Track Lc. |
-- под заказ |
|
| 26 | 404111200 Gicleur Mj 220 *jet-main 220 Skandic Wide Track Lc. |
445.17р под заказ |
|
| 404100300 Gicleur Mj 250 *jet-main 250 Skandic Wide Track Lc. |
877.80р под заказ |
||
| 28 | 404102000 Screw-w/lock *screw-w/lockwasher Skandic Wide Track Lc. |
354.26р под заказ |
|
| 30 | 404127600 Raccord *nipple Skandic Wide Track Lc. |
1'031.42р под заказ |
|
| 31 | 404127400 Ressort *spring Skandic Wide Track Lc. |
1'181.90р под заказ |
|
| 32 | 404160400 Plongeur Ass. *plunger-assy Skandic Wide Track Lc. |
3'522.70р под заказ |
|
| 33 | 404117000 Joint Tampon *packing Skandic Wide Track Lc. |
424.27р под заказ |
|
| 34 | 404160800 Connecteur *connector Skandic Wide Track Lc. |
1'806.81р под заказ |
|
| 35 | 404122100 Couvercle *cover Skandic Wide Track Lc. |
2'090.00р под заказ |
|
| 36 | 404154900 Bouchon *cap Skandic Wide Track Lc. |
1'716.94р под заказ |
|
| 37 | 404112000 Trousse Outils *tool Kit Skandic Wide Track Lc. |
10'942.20р под заказ |
Каталог несет в первую очередь справочную информацию, поэтому обращаем ваше внимание, что наличие деталей в каталоге не означает ее наличие на нашем складе.
